The W60 motor is designed to run on voltages ranging from 2300 V up to 13800 V power frequency of 50 or 60 Hz, thus serving the international market requirement. It has advanced cooling system options; IC01, IC611, and IC81W for operation in different climate conditions. Temperature is sensed by RTD Pt-100 sensors mounted within the shaft of the motor. To ensure an efficient starting process, the DOL (Direct On Line) starting method is applied, and the freedom of either unidirectional or bidirectional rotation can be useful for different usages. This motor has a stator connection box which comes with IP66 for that reason it is more reliable in any harsh condition.

• Rated Output: A power range of thousand kWs of power with the upper limit set at 7500 kW suitable for industrial uses.
• Voltage and Frequency: It can support Voltage of 2,300 V to 13,800 V and works at either 50 Hz or 60 Hz depending on the regions of the world.
• Cooling Methods: Introduces three models of cooling types which are the IC01, IC611, and the IC81W depending on operational temperatures.
• Temperature Monitoring: Under the category RTD Pt-100, it is identified for phase temperature measurement to assess safety and prevent overheating.
• Direct On Line (DOL) Start: The DOL starting method means easy and fast motor starting without the involvement of complex control systems.

• Installation: Make sure the motor is properly ventilated, so it does not get too hot, it is also easy to access for checks and adjustments.
• Regular Maintenance: Perform periodic temperature sensor checks on their performance and also frequently monitor the status of their bearing lubrication to minimize unnecessary halts.
• Environment Considerations: Install the motor in a location where the IP66 protection degree can fully protect it from such conditions as dust or moisture.
