Best Single Stage Air Compressor​ (PM VSD）

The JX-15APMS has an exhaust pressure of 0.8 MPa and an exhaust volume of 1.7 M3/min. It has an air-cooled cooling mode to facilitate good temperature control with an environmental maximum of 46°C allowed. The compressor implements a single-stage compression process and the exhaust oil content is ≤ 3ppm. It has an operating noise of < 6 dB(a) ±2 making it ideal for places with sensitive noise levels.

The compressor has a direct connection drive mode and this machine needs 6 liters of lubricant (Grade 46#). It is powered by a three-phase 380V/50Hz power supply though can be adjusted to suit any given requirement. It is intended for an ordinary temperature environment: maximum permissible pressure is 0,1033 MPa, and the relative humidity is 60%. The motor is rated for 15HP (11 kW) at an operating speed of 3000 RPM using variable frequency start. The protection grade is IP23 (optional) and the insulation grade is also F, because of which they are rugged and safe. These are: overall dimensions – 1000mm(W) x 750mm(D) x 1070mm(H), weight – 195Kg.

• Single-Stage Design: Also offers controlled air compression with less energy consumption than multi-stage air compressors.
• Air-Cooled Cooling Mode: It provides the best operating temperatures in a bid to enhance performance and durability.
• Low Operating Noise: Operationally silent, allowing this device to be suitable for installation in almost any industrial application.
• High Efficiency: You can achieve increased performance and energy-efficient operations through its rated power of 15 HP or 11 kW.
• Flexible Power Supply Options: It can even additionally be designed to meet particular voltage and frequency needs.
• Durable Construction: Made from strong metals and other durable materials that have protection IP23 for operation in different circumstances.

With the rise of global energy costs and environmental protection awareness, energy efficiency standards and environmental protection standards have been raised, and the market demand for high-efficiency, energy-saving, low-noise，intelligent air compressors is growing. JX-15APMS-15HP/11KW PM VSD screw air compressor is based on this background and developed products.

According to the needs of the site equipment, determine the required pressure and flow rate, consider the power, select the appropriate air compressor; compared with other brands, our production of VIBRANT brand air compressor, higher energy efficiency, cost-effective, good after-sales service, fast response in the event of equipment failure, is a good choice.

• Routine Maintenance: It is important to inspect and when necessary replace fluids, filters, and coolers to achieve maximum efficiency.
• Monitor Operating Conditions: The operating environment should be kept within some set parameters so that the electromechanical device does not overheat.
• Regular Inspections: It is necessary to perform periodic checks of all equipment and in particular check for wear on the wearing parts.
• Safety Protocols: Abide with all the safety measures recommended in the manufacturer’s manual, especially on aspects relating to electric parts and appropriate pressures.

• Manufacturing Facilities: suited for the operating of pneumatic devices as well as equipment used in production processes.
• Automotive Workshops: Select for supplying air in automotive repair and maintenance activities that require the equipment.
• Construction Sites: Applicable to supply air for tools and equipment rigorously used in construction industries.
• HVAC Services: Ideal for use when providing service or installing ACs with other relevant systems that need compressed air.
• General Industry: Effective in use in various industries whereby stable and steady air supply is desired.
